Refrigeration Capacity

Input Power

Efficiency

EVAP TEMP

COND TEMP

AMBIENT TEMP

RETURN GAS

LIQUID TEMP

Condition

Test Voltage

Btu/h

kcal/h

W

W

Btu/Wh

kcal/Wh

W/W

ASHRAE

460V 3~ 60HZ

33700

8492

9874

3500

9.63

2.43

2.82

7.2°C (45°F)

54°C (130°F)

35°C (95°F)

35°C (95°F)

46°C (115°F)

Evaporating Temp. Range:

-6.7°C to 12.8°C (20°F to 55°F)

Motor Torque:

High Start Torque (HST)

Compressor Cooling:

Fan

Weight:

105

Weight Unit of Measure:

N/A

Displacement (cc):

100.671

Oil Type:

Synthetic Alkylate

Viscosity (cSt):

53

Oil Charge (cc):

1955

Sound Power dB(A):

N/A

Voltage Range (50 Hz):

342-462

Voltage Range (60 Hz):

414-506

Locked Rotor Amps (LRA):

32

Rated Load Amps (RLA 50 Hz):

N/A

Rated Load Amps (RLA 60 Hz):

5.5

Max. Continuous Current (MCC in Amps):

8.7

Motor Resitance (Ohm) - Main:

5.94

Motor Resitance (Ohm) - Start:

0

Motor Type:

3PH

Overload Type:

N/A

Relay Type:

N/A
